Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
896 Freescale Semiconductor
Rx 14 Mask Register RX14MASK 32-bit Base + 0x0014
Rx 15 Mask Register RX15MASK 32-bit Base + 0x0018
Error Counter Register ECR 32-bit Base + 0x001C
Error and Status Register ESR 32-bit Base + 0x0020
Interrupt Masks 2 Register IMASK2 32-bit Base + 0x0024
Interrupt Masks 1 Register IMASK1 32-bit Base + 0x0028
Interrupt Flags 2 Register IFLAG2 32-bit Base + 0x002C
Interrupt Flags 1 Register IFLAG1 32-bit Base + 0x0030
Reserved — — Base + (0x0034 –
0x007F)
Message Buffer 0 MB0 128 bits
per MB
Base + 0x0080
Message Buffer 1 MB1 128 bits
per MB
Base + 0x0090
Message Buffer 2 MB2 128 bits
per MB
Base + 0x00A0
Message Buffer 3 MB3 128 bits
per MB
Base + 0x00B0
Message Buffer 4 MB4 128 bits
per MB
Base + 0x00C0
Message Buffer 5 MB5 128 bits
per MB
Base + 0x00D0
Message Buffer 6 MB6 128 bits
per MB
Base + 0x00E0
Message Buffer 7 MB7 128 bits
per MB
Base + 0x00F0
Message Buffer 8 MB8 128 bits
per MB
Base + 0x0100
Message Buffer 9 MB9 128 bits
per MB
Base + 0x0110
Message Buffer 10 MB10 128 bits
per MB
Base + 0x0120
Message Buffer 11 MB11 128 bits
per MB
Base + 0x0130
Message Buffer 12 MB12 128 bits
per MB
Base + 0x0140
Message Buffer 13 MB13 128 bits
per MB
Base + 0x0150
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
