Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 855
LIN control register 1 LINCR1 32-bit Base + 0x0000
LIN interrupt enable register LINIER 32-bit Base + 0x0004
LIN status register LINSR 32-bit Base + 0x0008
LIN error status register LINESR 32-bit Base + 0x000C
UART mode control register UARTCR 32-bit Base + 0x0010
UART mode status register UARTSR 32-bit Base + 0x0014
LIN timeout control status register LINTCSR 32-bit Base + 0x0018
LIN output compare register LINOCR 32-bit Base + 0x001C
LIN timeout control register LINTOCR 32-bit Base + 0x0020
LIN fractional baud rate register LINFBRR 32-bit Base + 0x0024
LIN integer baud rate register LINIBRR 32-bit Base + 0x0028
LIN checksum field register LINCFR 32-bit Base + 0x002C
LIN control register 2 LINCR2 32-bit Base + 0x0030
Buffer identifier register BIDR 32-bit Base + 0x0034
Buffer data register LSB BDRL 32-bit Base + 0x0038
Buffer data register MSB BDRM 32-bit Base + 0x003C
Reserved — — (Base + 0x0040)–
(Base + 0xBFFF)
LINFlex_3 0xFFE4_C000
LIN control register 1 LINCR1 32-bit Base + 0x0000
LIN interrupt enable register LINIER 32-bit Base + 0x0004
LIN status register LINSR 32-bit Base + 0x0008
LIN error status register LINESR 32-bit Base + 0x000C
UART mode control register UARTCR 32-bit Base + 0x0010
UART mode status register UARTSR 32-bit Base + 0x0014
LIN timeout control status register LINTCSR 32-bit Base + 0x0018
LIN output compare register LINOCR 32-bit Base + 0x001C
LIN timeout control register LINTOCR 32-bit Base + 0x0020
LIN fractional baud rate register LINFBRR 32-bit Base + 0x0024
LIN integer baud rate register LINIBRR 32-bit Base + 0x0028
LIN checksum field register LINCFR 32-bit Base + 0x002C
LIN control register 2 LINCR2 32-bit Base + 0x0030
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
