Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 849
Timer Flag Register 3 TFLG3 32-bit Base + 0x013C
Timer Load Value Register 4 LDVAL4 32-bit Base + 0x0140
Current Timer Value Register 4 CVAL4 32-bit Base + 0x0144
Timer Control Register 4 TCTRL4 32-bit Base + 0x0148
Timer Flag Register 4 TFLG4 32-bit Base + 0x014C
Timer Load Value Register 5 LDVAL5 32-bit Base + 0x0150
Current Timer Value Register 5 CVAL5 32-bit Base + 0x0154
Timer Control Register 5 TCTRL5 32-bit Base + 0x0158
Timer Flag Register 5 TFLG5 32-bit Base + 0x015C
Reserved — — Base + 0x0160 –
0x01FF
ADC 0xFFE0_0000
Main Configuration Register MCR 32-bit Base + 0x0000
Main Status Register MSR 32-bit Base + 0x0004
Reserved — — Base + 0x0008 –
0x000F
Interrupt Status Register ISR 32-bit Base + 0x0010
Channel Pending Register CEOCFR0 32-bit Base + 0x0014
Channel Pending Register CEOCFR1 32-bit Base + 0x0018
Channel Pending Register CEOCFR2 32-bit Base + 0x001C
Interrupt Mask Register IMR 32-bit Base + 0x0020
Channel Interrupt Mask Register CIMR0 32-bit Base + 0x0024
Channel Interrupt Mask Register CIMR1 32-bit Base + 0x0028
Channel Interrupt Mask Register CIMR2 32-bit Base + 0x002C
Watchdog Threshold Interrupt Status Register WTISR 32-bit Base + 0x0030
Watchdog Threshold Interrupt Mask Register WTIMR 32-bit Base + 0x0034
Reserved — — Base + 0x0038 –
0x004F
Threshold Control Register 0 TRC0 32-bit Base + 0x0050
Threshold Control Register 1 TRC1 32-bit Base + 0x0054
Threshold Control Register 2 TRC2 32-bit Base + 0x0058
Threshold Control Register 3 TRC3 32-bit Base + 0x005C
Threshold Register 0 THRHLR0 32-bit Base + 0x0060
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
