Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
854 Freescale Semiconductor
Identifier filter control register 4 IFCR4 32-bit Base + 0x005C
Identifier filter control register 5 IFCR5 32-bit Base + 0x0060
Identifier filter control register 6 IFCR6 32-bit Base + 0x0064
Identifier filter control register 7 IFCR7 32-bit Base + 0x0068
Identifier filter control register 8 IFCR8 32-bit Base + 0x006C
Identifier filter control register 9 IFCR9 32-bit Base + 0x0070
Identifier filter control register 10 IFCR10 32-bit Base + 0x0074
Identifier filter control register 11 IFCR11 32-bit Base + 0x0078
Identifier filter control register 12 IFCR12 32-bit Base + 0x007C
Identifier filter control register 13 IFCR13 32-bit Base + 0x0080
Identifier filter control register 14 IFCR14 32-bit Base + 0x0084
Identifier filter control register 15 IFCR15 32-bit Base + 0x0088
LINFlex_1 0xFFE4_4000
LIN control register 1 LINCR1 32-bit Base + 0x0000
LIN interrupt enable register LINIER 32-bit Base + 0x0004
LIN status register LINSR 32-bit Base + 0x0008
LIN error status register LINESR 32-bit Base + 0x000C
UART mode control register UARTCR 32-bit Base + 0x0010
UART mode status register UARTSR 32-bit Base + 0x0014
LIN timeout control status register LINTCSR 32-bit Base + 0x0018
LIN output compare register LINOCR 32-bit Base + 0x001C
LIN timeout control register LINTOCR 32-bit Base + 0x0020
LIN fractional baud rate register LINFBRR 32-bit Base + 0x0024
LIN integer baud rate register LINIBRR 32-bit Base + 0x0028
LIN checksum field register LINCFR 32-bit Base + 0x002C
LIN control register 2 LINCR2 32-bit Base + 0x0030
Buffer identifier register BIDR 32-bit Base + 0x0034
Buffer data register LSB BDRL 32-bit Base + 0x0038
Buffer data register MSB BDRM 32-bit Base + 0x003C
Reserved — — (Base + 0x0040)–
(Base + 0x7FFF)
LINFlex_2 0xFFE4_8000
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
