1.7 Using the MPC5604B
There are many different approaches to designing a system using the MPC5604B so the guidance in this
section is provided as an example of how the documents can be applied in this task.
Familiarity with the MPC5604B modules can help ensure that its features are being optimally used in a
system design. Therefore, the current chapter is a good starting point. Further information on the detailed
features of a module are provided within the module chapters. These, combined with the current chapter,
should provide a good introduction to the functions available on the MCU.
1.7.1 Hardware design
The MPC5604B requires that certain pins are connected to particular power supplies, system functions and
other voltage levels for operation.
Table 1-2. Reference manual integration and functional content
Chapter Integration content Functional content
Introduction • The main features on chip
• A summary of the functions provided by
each module
—
Memory Map How the memory map is allocated,
including:
• Internal RAM
• Flash memory
• External memory-mapped resources
and the location of the registers used by
the peripherals
1
1
To find the address of a register in a particular module take the start address of the module given in the memory
map and add the offset for the register given in the module chapter.
—
Signal Description How the signals from each of the modules
are combined and brought to a particular
pin on a package
—
Boot Assist Module CPU boot sequence from reset Implementation of the boot options if
internal flash memory is not used
Clock Description Clocking architecture of the device (which
clock is available for the system and each
peripheral)
Description of operation of different clock
sources
Interrupt Controller Interrupt vector table Operation of the module
Mode Entry Module Module numbering for control and status Operation of operating modes
System Integration Unit
Lite
How input signals are mapped to individual
modules including external interrupt pins
Operation of GPIO
Voltage regulators and
power supplies
Power distribution to the MCU —
Wakeup Unit Allocation of inputs to the Wakeup Unit Operation of the wakeup feature
