eMIOS_1 UC9 Status Register eMIOS1_UC9_SS 32-bit Base + 0x0150
Reserved — — Base + 0x0154 –
Base + 0x015F
eMIOS_1 UC10 A Register eMIOS1_UC10_A 32-bit Base + 0x0160
eMIOS_1 UC10 B Register eMIOS1_UC10_B 32-bit Base + 0x0164
Reserved — — Base + 0x0168 –
Base + 0x016B
eMIOS_1 UC10 Control Register eMIOS1_UC10_SC 32-bit Base + 0x016C
eMIOS_1 UC10 Status Register eMIOS1_UC10_SS 32-bit Base + 0x0170
Reserved — — Base + 0x0174 –
Base + 0x017F
eMIOS_1 UC11 A Register eMIOS1_UC11_A 32-bit Base + 0x0180
eMIOS_1 UC11 B Register eMIOS1_UC11_B 32-bit Base + 0x0184
Reserved — — Base + 0x0188 –
Base + 0x018B
eMIOS_1 UC11 Control Register eMIOS1_UC11_SC 32-bit Base + 0x018C
eMIOS_1 UC11 Status Register eMIOS1_UC11_SS 32-bit Base + 0x0190
Reserved — — Base + 0x0194 –
Base + 0x019F
eMIOS_1 UC12 A Register eMIOS1_UC12_A 32-bit Base + 0x01A0
eMIOS_1 UC12 B Register eMIOS1_UC12_B 32-bit Base + 0x01A4
Reserved — — Base + 0x01A8 –
Base + 0x01AB
eMIOS_1 UC12 Control Register eMIOS1_UC12_SC 32-bit Base + 0x01AC
eMIOS_1 UC12 Status Register eMIOS1_UC12_SS 32-bit Base + 0x01B0
Reserved — — Base + 0x01B4 –
Base + 0x01BF
eMIOS_1 UC13 A Register eMIOS1_UC13_A 32-bit Base + 0x01C0
eMIOS_1 UC13 B Register eMIOS1_UC13_B 32-bit Base + 0x01C4
Reserved — — Base + 0x01C8 –
Base + 0x01CB
eMIOS_1 UC13 Control Register eMIOS1_UC13_SC 32-bit Base + 0x01CC
eMIOS_1 UC13 Status Register eMIOS1_UC13_SS 32-bit Base + 0x01D0
Reserved — — Base + 0x01D4 –
Base + 0x01DF
eMIOS_1 UC14 A Register eMIOS1_UC14_A 32-bit Base + 0x01E0
Table A-2. Detailed register map (continued)
