Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 853
I2C Bus Address Register IBAD 8-bit Base + 0x0000
I2C Bus Frequency Divider Register IBFD 8-bit Base + 0x0001
I2C Bus Control Register IBCR 8-bit Base + 0x0002
I2C Bus Status Register IBSR 8-bit Base + 0x0003
I2C Bus Data I/O Register IBDR 8-bit Base + 0x0004
I2C Bus Interrupt Configuration Register IBIC 8-bit Base + 0x0005
Reserved — — (Base + 0x0006) –
(Base + 0xFFFF)
LINFlex_0 0xFFE4_0000
LIN control register 1 LINCR1 32-bit Base + 0x0000
LIN interrupt enable register LINIER 32-bit Base + 0x0004
LIN status register LINSR 32-bit Base + 0x0008
LIN error status register LINESR 32-bit Base + 0x000C
UART mode control register UARTCR 32-bit Base + 0x0010
UART mode status register UARTSR 32-bit Base + 0x0014
LIN timeout control status register LINTCSR 32-bit Base + 0x0018
LIN output compare register LINOCR 32-bit Base + 0x001C
LIN timeout control register LINTOCR 32-bit Base + 0x0020
LIN fractional baud rate register LINFBRR 32-bit Base + 0x0024
LIN integer baud rate register LINIBRR 32-bit Base + 0x0028
LIN checksum field register LINCFR 32-bit Base + 0x002C
LIN control register 2 LINCR2 32-bit Base + 0x0030
Buffer identifier register BIDR 32-bit Base + 0x0034
Buffer data register LSB BDRL 32-bit Base + 0x0038
Buffer data register MSB BDRM 32-bit Base + 0x003C
Identifier filter enable register IFER 32-bit Base + 0x0040
Identifier filter match index IFMI 32-bit Base + 0x0044
Identifier filter mode register IFMR 32-bit Base + 0x0048
Identifier filter control register 0 IFCR0 32-bit Base + 0x004C
Identifier filter control register 1 IFCR1 32-bit Base + 0x0050
Identifier filter control register 2 IFCR2 32-bit Base + 0x0054
Identifier filter control register 3 IFCR3 32-bit Base + 0x0058
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
