MPC5604B/C Microcontroller Reference Manual, Rev. 8
876 Freescale Semiconductor
Message Buffer 60 MB60 128 bits
per MB
Base + 0x0440
Message Buffer 61 MB61 128 bits
per MB
Base + 0x0450
Message Buffer 62 MB62 128 bits
per MB
Base + 0x0460
Message Buffer 63 MB63 128 bits
per MB
Base + 0x0470
Reserved — — (Base + 0x0480) –
(Base + 0x087F)
RX Individual Mask Register 0 RXIMR0 32-bit Base + 0x0880
RX Individual Mask Register 1 RXIMR1 32-bit Base + 0x0884
RX Individual Mask Register 2 RXIMR2 32-bit Base + 0x0888
RX Individual Mask Register 3 RXIMR3 32-bit Base + 0x088C
RX Individual Mask Register 4 RXIMR4 32-bit Base + 0x0890
RX Individual Mask Register 5 RXIMR5 32-bit Base + 0x0894
RX Individual Mask Register 6 RXIMR6 32-bit Base + 0x0898
RX Individual Mask Register 7 RXIMR7 32-bit Base + 0x089C
RX Individual Mask Register 8 RXIMR8 32-bit Base + 0x08A0
RX Individual Mask Register 9 RXIMR9 32-bit Base + 0x08A4
RX Individual Mask Register 10 RXIMR10 32-bit Base + 0x08A8
RX Individual Mask Register 11 RXIMR11 32-bit Base + 0x08AC
RX Individual Mask Register 12 RXIMR12 32-bit Base + 0x08B0
RX Individual Mask Register 13 RXIMR13 32-bit Base + 0x08B4
RX Individual Mask Register 14 RXIMR14 32-bit Base + 0x08B8
RX Individual Mask Register 15 RXIMR15 32-bit Base + 0x08BC
RX Individual Mask Register 16 RXIMR16 32-bit Base + 0x08C0
RX Individual Mask Register 17 RXIMR17 32-bit Base + 0x08C4
RX Individual Mask Register 18 RXIMR18 32-bit Base + 0x08C8
RX Individual Mask Register 19 RXIMR19 32-bit Base + 0x08CC
RX Individual Mask Register 20 RXIMR20 32-bit Base + 0x08D0
RX Individual Mask Register 21 RXIMR21 32-bit Base + 0x08D4
RX Individual Mask Register 22 RXIMR22 32-bit Base + 0x08D8
RX Individual Mask Register 23 RXIMR23 32-bit Base + 0x08DC
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
