MPC5604B/C Microcontroller Reference Manual, Rev. 8
844 Freescale Semiconductor
Reserved — — Base + 0x0044 –
Base + 0x0047
STOP Mode Configuration ME_STOP_MC 32-bit Base + 0x0048
Reserved — — Base + 0x004C –
Base + 0x0053
STANDBY Mode Configuration ME_STANDBY_MC 32-bit Base + 0x0054
Reserved — — Base + 0x0058 –
Base + 0x005F
Peripheral Status Registers ME_PS0 32-bit Base + 0x0060
Peripheral Status Registers ME_PS1 32-bit Base + 0x0064
Peripheral Status Registers ME_PS2 32-bit Base + 0x0068
Peripheral Status Registers ME_PS3 32-bit Base + 0x006C
Reserved — — (Base + 0x0070) –
(Base + 0x007F)
RUN Peripheral Configuration Registers ME_RUN_PC0 32-bit Base + 0x0080
RUN Peripheral Configuration Registers ME_RUN_PC1 32-bit Base + 0x0084
RUN Peripheral Configuration Registers ME_RUN_PC2 32-bit Base + 0x0088
RUN Peripheral Configuration Registers ME_RUN_PC3 32-bit Base + 0x008C
RUN Peripheral Configuration Registers ME_RUN_PC4 32-bit Base + 0x0090
RUN Peripheral Configuration Registers ME_RUN_PC5 32-bit Base + 0x0094
RUN Peripheral Configuration Registers ME_RUN_PC6 32-bit Base + 0x0098
RUN Peripheral Configuration Registers ME_RUN_PC7 32-bit Base + 0x009C
Low Power Peripheral Configuration Registers ME_LP_PC0 32-bit Base + 0x00A0
Low Power Peripheral Configuration Registers ME_LP_PC1 32-bit Base + 0x00A4
Low Power Peripheral Configuration Registers ME_LP_PC2 32-bit Base + 0x00A8
Low Power Peripheral Configuration Registers ME_LP_PC3 32-bit Base + 0x00AC
Low Power Peripheral Configuration Registers ME_LP_PC4 32-bit Base + 0x00B0
Low Power Peripheral Configuration Registers ME_LP_PC5 32-bit Base + 0x00B4
Low Power Peripheral Configuration Registers ME_LP_PC6 32-bit Base + 0x00B8
Low Power Peripheral Configuration Registers ME_LP_PC7 32-bit Base + 0x00BC
Reserved — — (Base + 0x00C0) –
(Base + 0x00C3)
DSPI0 Control ME_PCTL4 8-bit Base + 0x00C4
DSPI1 Control ME_PCTL5 8-bit Base + 0x00C5
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
