Pad Selection for Multiplexed Inputs PSMI0_3 32-bit Base + 0x0500
Pad Selection for Multiplexed Inputs PSMI4_7 32-bit Base + 0x0504
Pad Selection for Multiplexed Inputs PSMI8_11 32-bit Base + 0x0508
Pad Selection for Multiplexed Inputs PSMI12_15 32-bit Base + 0x050C
Pad Selection for Multiplexed Inputs PSMI16_19 32-bit Base + 0x0510
Pad Selection for Multiplexed Inputs PSMI20_23 32-bit Base + 0x0514
Pad Selection for Multiplexed Inputs PSMI24_27 32-bit Base + 0x0518
Pad Selection for Multiplexed Inputs PSMI28_31 32-bit Base + 0x051C
Reserved — — Base + (0x0520 –
0x05FF)
GPIO Pad Data Output Register GPDO0_3 32-bit Base + 0x0600
GPIO Pad Data Output Register GPDO4_7 32-bit Base + 0x0604
GPIO Pad Data Output Register GPDO8_11 32-bit Base + 0x0608
GPIO Pad Data Output Register GPDO12_15 32-bit Base + 0x060C
GPIO Pad Data Output Register GPDO16_19 32-bit Base + 0x0610
GPIO Pad Data Output Register GPDO20_23 32-bit Base + 0x0614
GPIO Pad Data Output Register GPDO24_27 32-bit Base + 0x0618
GPIO Pad Data Output Register GPDO28_31 32-bit Base + 0x061C
GPIO Pad Data Output Register GPDO32_35 32-bit Base + 0x0620
GPIO Pad Data Output Register GPDO36_39 32-bit Base + 0x0624
GPIO Pad Data Output Register GPDO40_43 32-bit Base + 0x0628
GPIO Pad Data Output Register GPDO44_47 32-bit Base + 0x062C
GPIO Pad Data Output Register GPDO48_51 32-bit Base + 0x0630
GPIO Pad Data Output Register GPDO52_55 32-bit Base + 0x0634
GPIO Pad Data Output Register GPDO56_59 32-bit Base + 0x0638
GPIO Pad Data Output Register GPDO60_63 32-bit Base + 0x063C
GPIO Pad Data Output Register GPDO64_67 32-bit Base + 0x0640
GPIO Pad Data Output Register GPDO68_71 32-bit Base + 0x0644
GPIO Pad Data Output Register GPDO72_75 32-bit Base + 0x0648
GPIO Pad Data Output Register GPDO76_79 32-bit Base + 0x064C
GPIO Pad Data Output Register GPDO80_83 32-bit Base + 0x0650
GPIO Pad Data Output Register GPDO84_87 32-bit Base + 0x0654
