MPC5604B/C Microcontroller Reference Manual, Rev. 8

Freescale Semiconductor 845

DSPI2 Control ME_PCTL6 8-bit Base + 0x00C6

Reserved — — (Base + 0x00C7) –

(Base + 0x00CF)

FlexCAN0 Control ME_PCTL16 8-bit Base + 0x00D0

FlexCAN1 Control ME_PCTL17 8-bit Base + 0x00D1

FlexCAN2 Control ME_PCTL18 8-bit Base + 0x00D2

FlexCAN3 Control ME_PCTL19 8-bit Base + 0x00D3

FlexCAN4 Control ME_PCTL20 8-bit Base + 0x00D4

FlexCAN5 Control ME_PCTL21 8-bit Base + 0x00D5

Reserved — — (Base + 0x00D6) –

(Base + 0x00DF)

ADC0 Control ME_PCTL32 8-bit Base + 0x00E0

Reserved — — (Base + 0x00E1) –

(Base + 0x00EB)

I2C0 Control ME_PCTL44 8-bit Base + 0x00EC

Reserved — — (Base + 0x00ED) –

(Base + 0x00EF)

LINFlex0 Control ME_PCTL48 8-bit Base + 0x00F0

LINFlex1 Control ME_PCTL49 8-bit Base + 0x00F1

LINFlex2 Control ME_PCTL50 8-bit Base + 0x00F2

LINFlex3 Control ME_PCTL51 8-bit Base + 0x00F3

Reserved — — (Base + 0x00F4) –

(Base + 0x00F8)

CTU Control ME_PCTL57 8-bit Base + 0x00F9

Reserved — — (Base + 0x00FA) –

(Base + 0x00FB)

CAN Sampler Control ME_PCTL60 8-bit Base + 0x00FC

Reserved — — (Base + 0x00FD) –

(Base + 0x0103)

SIUL Control ME_PCTL68 8-bit Base + 0x0104

WKPU Control ME_PCTL69 8-bit Base + 0x0105

Reserved — — (Base + 0x0106) –

(Base + 0x0107)

eMIOS0 Control ME_PCTL72 8-bit Base + 0x0108

eMIOS1 Control ME_PCTL73 8-bit Base + 0x0109

Table A-2. Detailed register map (continued)

Used

size

Address
