Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
838 Freescale Semiconductor
eMIOS_1 UC0 Status Register eMIOS1_UC0_SS 32-bit Base + 0x0030
Reserved — — Base + 0x0034 –
Base + 0x003F
eMIOS_1 UC1 A Register eMIOS1_UC1_A 32-bit Base + 0x0040
eMIOS_1 UC1 B Register eMIOS1_UC1_B 32-bit Base + 0x0044
Reserved — — Base + 0x0048 –
Base + 0x004B
eMIOS_1 UC1 Control Register eMIOS1_UC1_SC 32-bit Base + 0x004C
eMIOS_1 UC1 Status Register eMIOS1_UC1_SS 32-bit Base + 0x0050
Reserved — — Base + 0x0054 –
Base + 0x005F
eMIOS_1 UC2 A Register eMIOS1_UC2_A 32-bit Base + 0x0060
eMIOS_1 UC2 B Register eMIOS1_UC2_B 32-bit Base + 0x0064
Reserved — — Base + 0x0068 –
Base + 0x006B
eMIOS_1 UC2 Control Register eMIOS1_UC2_SC 32-bit Base + 0x006C
eMIOS_1 UC2 Status Register eMIOS1_UC2_SS 32-bit Base + 0x0070
Reserved — — Base + 0x0074 –
Base + 0x007F
eMIOS_1 UC3 A Register eMIOS1_UC3_A 32-bit Base + 0x0080
eMIOS_1 UC3 B Register eMIOS1_UC3_B 32-bit Base + 0x0084
Reserved — — Base + 0x0088 –
Base + 0x008B
eMIOS_1 UC3 Control Register eMIOS1_UC3_SC 32-bit Base + 0x008C
eMIOS_1 UC3 Status Register eMIOS1_UC3_SS 32-bit Base + 0x0090
Reserved — — Base + 0x0094 –
Base + 0x009F
eMIOS_1 UC4 A Register eMIOS1_UC4_A 32-bit Base + 0x00A0
eMIOS_1 UC4 B Register eMIOS1_UC4_B 32-bit Base + 0x00A4
Reserved — — Base + 0x00A8 –
Base + 0x00AB
eMIOS_1 UC4 Control Register eMIOS1_UC4_SC 32-bit Base + 0x00AC
eMIOS_1 UC4 Status Register eMIOS1_UC4_SS 32-bit Base + 0x00B0
Reserved — — Base + 0x00B4 –
Base + 0x00BF
eMIOS_1 UC5 A Register eMIOS1_UC5_A 32-bit Base + 0x00C0
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
