Appendix A
Register Map
Table A-1. Module base addresses
Module name Base addresses Page
Code Flash A Configuration 0xC3F8_8000 on page 822
Data Flash A Configuration 0xC3F8_C000 on page 823
System Integration Unit Lite (SIUL) 0xC3F9_0000 on page 823
WakeUp Unit 0xC3F9_4000 on page 823
eMIOS_0 0xC3FA_0000 on page 832
eMIOS_1 0xC3FA_4000 on page 837
System Status and Configuration Module (SSCM) 0xC3FD_8000 on page 843
Mode Entry Module (MC_ME) 0xC3FD_C000 on page 843
FXOSC 0xC3FE_0000 on page 846
SXOSC 0xC3FE_0040 on page 846
FIRC 0xC3FE_0060 on page 846
SIRC 0xC3FE_0080 on page 846
FMPLL 0xC3FE_00A0 on page 846
CMU 0xC3FE_0100 on page 846
Clock Generation Module (MC_CGM) 0xC3FE_0370 on page 847
Reset Generation Module (MC_RGM) 0xC3FE_4000 on page 847
Power Control Unit (MC_PCU) 0xC3FE_8000 on page 847
Real Time Counter (RTC/API) 0xC3FE_C000 on page 848
Periodic Interrupt Timer (PIT) 0xC3FF_0000 on page 848
ADC 0xFFE0_0000 on page 849
I2C 0xFFE3_0000 on page 852
LINFlex_0 0xFFE4_0000 on page 853
LINFlex_1 0xFFE4_4000 on page 854
LINFlex_2 0xFFE4_8000 on page 854
LINFlex_3 0xFFE4_C000 on page 855
CTU 0xFFE6_4000 on page 856
CAN sampler 0xFFE7_0000 on page 858
MPU 0xFFF1_0000 on page 858
SWT 0xFFF3_8000 on page 859
