Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
834 Freescale Semiconductor
eMIOS_0 UC7 Control Register EMIOS0_UC7_SC 32-bit Base + 0x010C
eMIOS_0 UC7 Status Register EMIOS0_UC7_SS 32-bit Base + 0x0110
Reserved — — Base + 0x0114 –
Base + 0x011F
eMIOS_0 UC8 A Register EMIOS0_UC8_A 32-bit Base + 0x0120
eMIOS_0 UC8 B Register EMIOS0_UC8_B 32-bit Base + 0x0124
eMIOS_0 UC8 CNT EMIOS0_UC8_CNT 32-bit Base + 0x0128
eMIOS_0 UC8 Control Register EMIOS0_UC8_SC 32-bit Base + 0x012C
eMIOS_0 UC8 Status Register EMIOS0_UC8_SS 32-bit Base + 0x0130
Reserved — — Base + 0x0134 –
Base + 0x013F
eMIOS_0 UC9 A Register EMIOS0_UC9_A 32-bit Base + 0x0140
eMIOS_0 UC9 B Register EMIOS0_UC9_B 32-bit Base + 0x0144
Reserved — — Base + 0x0148 –
Base + 0x014B
eMIOS_0 UC9 Control Register EMIOS0_UC9_SC 32-bit Base + 0x014C
eMIOS_0 UC9 Status Register EMIOS0_UC9_SS 32-bit Base + 0x0150
Reserved — — Base + 0x0154 –
Base + 0x015F
eMIOS_0 UC10 A Register EMIOS0_UC10_A 32-bit Base + 0x0160
eMIOS_0 UC10 B Register EMIOS0_UC10_B 32-bit Base + 0x0164
Reserved — — Base + 0x0168 –
Base + 0x016B
eMIOS_0 UC10 Control Register EMIOS0_UC10_SC 32-bit Base + 0x016C
eMIOS_0 UC10 Status Register EMIOS0_UC10_SS 32-bit Base + 0x0170
Reserved — — Base + 0x0174 –
Base + 0x017F
eMIOS_0 UC11 A Register EMIOS0_UC11_A 32-bit Base + 0x0180
eMIOS_0 UC11 B Register EMIOS0_UC11_B 32-bit Base + 0x0184
Reserved — — Base + 0x0188 –
Base + 0x018B
eMIOS_0 UC11 Control Register EMIOS0_UC11_SC 32-bit Base + 0x018C
eMIOS_0 UC11 Status Register EMIOS0_UC11_SS 32-bit Base + 0x0190
Reserved — — Base + 0x0194 –
Base + 0x019F
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
