MPC5604B/C Microcontroller Reference Manual, Rev. 8
858 Freescale Semiconductor
Event Configuration Register57 CTU_EVTCFGR57 32-bit Base + 0x0114
Event Configuration Register58 CTU_EVTCFGR58 32-bit Base + 0x0118
Event Configuration Register59 CTU_EVTCFGR59 32-bit Base + 0x011C
Event Configuration Register60 CTU_EVTCFGR60 32-bit Base + 0x0120
Event Configuration Register61 CTU_EVTCFGR61 32-bit Base + 0x0124
Event Configuration Register62 CTU_EVTCFGR62 32-bit Base + 0x0128
Event Configuration Register63 CTU_EVTCFGR63 32-bit Base + 0x012C
Reserved — — (Base + 0x0130) –
0xFFE6_FFFF
CAN Sampler 0xFFE7_0000
Control Status Register CANS_CR 32-bit Base + 0x0000
Sample Register 0 CAN_SR0 32-bit Base + 0x0004
Sample Register 1 CAN_SR1 32-bit Base + 0x0008
Sample Register 2 CAN_SR2 32-bit Base + 0x000C
Sample Register 3 CAN_SR3 32-bit Base + 0x0010
Sample Register 4 CAN_SR4 32-bit Base + 0x0014
Sample Register 5 CAN_SR5 32-bit Base + 0x0018
Sample Register 6 CAN_SR6 32-bit Base + 0x001C
Sample Register 7 CAN_SR7 32-bit Base + 0x0020
Sample Register 8 CAN_SR8 32-bit Base + 0x0024
Sample Register 9 CAN_SR9 32-bit Base + 0x0028
Sample Register 10 CAN_SR10 32-bit Base + 0x002C
Sample Register 11 CAN_SR11 32-bit Base + 0x0030
Reserved — — (Base + 0x0034) –
0xFFF0_FFFF
MPU 0xFFF1_0000
MPU Control/Error Status Register MPU_CESR 32-bit Base + 0x0000
Reserved — — Base + 0x0004 –
Base + 0x000F
MPU Error Address Register, Slave Port 0 MPU_EAR0 32-bit Base + 0x0010
MPU Error Detail Register, Slave Port 0 MPU_EDR0 32-bit Base + 0x0014
MPU Error Address Register, Slave Port 1 MPU_EAR1 32-bit Base + 0x0018
MPU Error Detail Register, Slave Port 1 MPU_EDR1 32-bit Base + 0x001c
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
