25.4 Register descriptions
25.4.1 Introduction
Table 25-6 lists ADC_0 registers with their address offsets and reset values.
Table 25-6. ADC_0 digital registers
Base address: 0xFFE0_0000
Location
Address offset Register name
0x0000 Main Configuration Register (MCR) on page 607
0x0004 Main Status Register (MSR) on page 609
0x0008 .. 0x000F Reserved —
0x0010 Interrupt Status Register (ISR) on page 611
0x0014 Channel Pending Register (CEOCFR0) on page 611
0x0018 Channel Pending Register (CEOCFR1) on page 611
0x001C Channel Pending Register (CEOCFR2) on page 611
0x0020 Interrupt Mask Register (IMR) on page 613
0x0024 Channel Interrupt Mask Register (CIMR0) on page 614
0x0028 Channel Interrupt Mask Register (CIMR1) on page 614
0x002C Channel Interrupt Mask Register (CIMR2) on page 614
0x0030 Watchdog Threshold Interrupt Status Register (WTISR) on page 616
0x0034 Watchdog Threshold Interrupt Mask Register (WTIMR) on page 616
0x0038 .. 0x004F Reserved —
0x0050 Threshold Control Register 0 (TRC0) on page 618
0x0054 Threshold Control Register 1 (TRC1) on page 618
0x0058 Threshold Control Register 2 (TRC2) on page 618
0x005C Threshold Control Register 3 (TRC3) on page 618
0x0060 Threshold Register 0 (THRHLR0) on page 619
0x0064 Threshold Register 1 (THRHLR1) on page 619
0x0068 Threshold Register 2 (THRHLR2) on page 619
0x006C Threshold Register 3 (THRHLR3) on page 619
0x0080 Presampling Control Register (PSCR) on page 619
0x0084 Presampling Register 0 (PSR0) on page 620
0x0088 Presampling Register 1 (PSR1) on page 620
0x008C Presampling Register 2 (PSR2) on page 620
0x0090 .. 0x0093 Reserved —
