0x0094 Conversion Timing Register 0 (CTR0) on page 622
0x0098 Conversion Timing Register 1 (CTR1) on page 622
0x009C Conversion Timing Register 2 (CTR2) on page 622
0x00A0 .. 0x00A3 Reserved —
0x00A4 Normal Conversion Mask Register 0 (NCMR0) on page 623
0x00A8 Normal Conversion Mask Register 1 (NCMR1) on page 623
0x00AC Normal Conversion Mask Register 2 (NCMR2) on page 623
0x00B0 .. 0x00B3 Reserved —
0x00B4 Injected Conversion Mask Register 0 (JCMR0) on page 625
0x00B8 Injected Conversion Mask Register 1 (JCMR1) on page 625
0x00BC Injected Conversion Mask Register 2 (JCMR2) on page 625
0x00C0 .. 0x00C3 Reserved —
0x00C4 Decode Signals Delay Register (DSDR) on page 627
0x00C8 Power-down Exit Delay Register (PDEDR) on page 627
0x00CC .. 0x00FF Reserved —
0x0100 Channel 0 Data Register (CDR0) on page 628
0x0104 Channel 1 Data Register (CDR1) on page 628
0x0108 Channel 2 Data Register (CDR2) on page 628
0x010C Channel 3 Data Register (CDR3) on page 628
0x0110 Channel 4 Data Register (CDR4) on page 628
0x0114 Channel 5 Data Register (CDR5) on page 628
0x0118 Channel 6 Data Register (CDR6) on page 628
0x011C Channel 7 Data Register (CDR7) on page 628
0x0120 Channel 8 Data Register (CDR8) on page 628
0x0124 Channel 9 Data Register (CDR9) on page 628
0x0128 Channel 10 Data Register (CDR10) on page 628
0x012C Channel 11 Data Register (CDR11) on page 628
0x0130 Channel 12 Data Register (CDR12) on page 628
0x0134 Channel 13 Data Register (CDR13) on page 628
0x0138 Channel 14 Data Register (CDR14) on page 628
0x013C Channel 15 Data Register (CDR15) on page 628
Table 25-6. ADC_0 digital registers (continued)
Base address: 0xFFE0_0000
Location
Address offset Register name
