MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 825
Pad Configuration Register 29 PCR29 16-bit Base + 0x007A
Pad Configuration Register 30 PCR30 16-bit Base + 0x007C
Pad Configuration Register 31 PCR31 16-bit Base + 0x007E
Pad Configuration Register 32 PCR32 16-bit Base + 0x0080
Pad Configuration Register 33 PCR33 16-bit Base + 0x0082
Pad Configuration Register 34 PCR34 16-bit Base + 0x0084
Pad Configuration Register 35 PCR35 16-bit Base + 0x0086
Pad Configuration Register 36 PCR36 16-bit Base + 0x0088
Pad Configuration Register 37 PCR37 16-bit Base + 0x008A
Pad Configuration Register 38 PCR38 16-bit Base + 0x008C
Pad Configuration Register 39 PCR39 16-bit Base + 0x008E
Pad Configuration Register 40 PCR40 16-bit Base + 0x0090
Pad Configuration Register 41 PCR41 16-bit Base + 0x0092
Pad Configuration Register 42 PCR42 16-bit Base + 0x0094
Pad Configuration Register 43 PCR43 16-bit Base + 0x0096
Pad Configuration Register 44 PCR44 16-bit Base + 0x0098
Pad Configuration Register 45 PCR45 16-bit Base + 0x009A
Pad Configuration Register 46 PCR46 16-bit Base + 0x009C
Pad Configuration Register 47 PCR47 16-bit Base + 0x009E
Pad Configuration Register 48 PCR48 16-bit Base + 0x00A0
Pad Configuration Register 49 PCR49 16-bit Base + 0x00A2
Pad Configuration Register 50 PCR50 16-bit Base + 0x00A4
Pad Configuration Register 51 PCR51 16-bit Base + 0x00A6
Pad Configuration Register 52 PCR52 16-bit Base + 0x00A8
Pad Configuration Register 53 PCR53 16-bit Base + 0x00AA
Pad Configuration Register 54 PCR54 16-bit Base + 0x00AC
Pad Configuration Register 55 PCR55 16-bit Base + 0x00AE
Pad Configuration Register 56 PCR56 16-bit Base + 0x00B0
Pad Configuration Register 57 PCR57 16-bit Base + 0x00B2
Pad Configuration Register 58 PCR58 16-bit Base + 0x00B4
Pad Configuration Register 59 PCR59 16-bit Base + 0x00B6
Pad Configuration Register 60 PCR60 16-bit Base + 0x00B8
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
