Freescale Semiconductor MPC5604B - Presampling Registers

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 619
25.4.4.3 Threshold Register (THRHLR[0:3])
The four THRHLRn registers are used to store the user-programmable thresholds’ 10-bit values.
25.4.5 Presampling registers
25.4.5.1 Presampling Control Register (PSCR)
Address: Base + 0x0060 (THRHLR0)
Base + 0x0064 (THRHLR1)
Base + 0x0068 (THRHLR2)
Base + 0x006C (THRHLR3) Access: User read/write
0123456789101112131415
R000000
THRH
W
Reset0000001111111111
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R000000
THRL
W
Reset0000000000000000
Figure 25-21. Threshold Register (THRHLR[0:3])
Table 25-16. THRHLRx field descriptions
Field Description
THRH High threshold value for channel n.
THRL Low threshold value for channel n.
Address: Base + 0x0080 Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R00000000 0
PREVAL2 PREVAL1 PREVAL0
PRE
CONV
W
Reset0000000000000000
Figure 25-22. Presampling Control Register (PSCR)
