Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 851
Channel 6 Data Register CDR6 32-bit Base + 0x0118
Channel 7 Data Register CDR7 32-bit Base + 0x011C
Channel 8 Data Register CDR8 32-bit Base + 0x0120
Channel 9 Data Register CDR9 32-bit Base + 0x0124
Channel 10 Data Register CDR10 32-bit Base + 0x0128
Channel 11 Data Register CDR11 32-bit Base + 0x012C
Channel 12 Data Register CDR12 32-bit Base + 0x0130
Channel 13 Data Register CDR13 32-bit Base + 0x0134
Channel 14 Data Register CDR14 32-bit Base + 0x0138
Channel 15 Data Register CDR15 32-bit Base + 0x013C
Reserved — — Base + 0x0140 –
0x017F
Channel 32 Data Register CDR32 32-bit Base + 0x0180
Channel 33 Data Register CDR33 32-bit Base + 0x0184
Channel 34 Data Register CDR34 32-bit Base + 0x0188
Channel 35 Data Register CDR35 32-bit Base + 0x018C
Channel 36 Data Register CDR36 32-bit Base + 0x0190
Channel 37 Data Register CDR37 32-bit Base + 0x0194
Channel 38 Data Register CDR38 32-bit Base + 0x0198
Channel 39 Data Register CDR39 32-bit Base + 0x019C
Channel 40 Data Register CDR40 32-bit Base + 0x01A0
Channel 41 Data Register CDR41 32-bit Base + 0x01A4
Channel 42 Data Register CDR42 32-bit Base + 0x01A8
Channel 43 Data Register CDR43 32-bit Base + 0x01AC
Channel 44 Data Register CDR44 32-bit Base + 0x01B0
Channel 45 Data Register CDR45 32-bit Base + 0x01B4
Channel 46 Data Register CDR46 32-bit Base + 0x01B8
Channel 47 Data Register CDR47 32-bit Base + 0x01BC
Reserved — — Base + 0x01C0 –
0x01FF
Channel 64 Data Register CDR64 32-bit Base + 0x0200
Channel 65 Data Register CDR65 32-bit Base + 0x0204
Channel 66 Data Register CDR66 32-bit Base + 0x0208
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
