Reserved — — (Base + 0x010A) –
(Base + 0x011A)
RTC_API Control ME_PCTL91 8-bit Base + 0x011B
PIT Control ME_PCTL92 8-bit Base + 0x011C
Reserved — — (Base + 0x011D) –
(Base + 0x0127)
CMU Control ME_PCTL104 8-bit Base + 0x0128
Reserved — — (Base + 0x0129) –
(Base + 0x014F)
FXOSC 0xC3FE_0000
Fast External Crystal Oscillator Control Register FXOSC_CTL 32-bit Base + 0x0000
Reserved — — (Base + 0x0004) –
(Base + 0x003F)
SXOSC 0xC3FE_0040
Slow External Crystal Oscillator Control Register SXOSC_CTL 32-bit Base + 0x0000
Reserved — — (Base + 0x0004) –
(Base + 0x005F)
FIRC Digital Interface 0xC3FE_0060
RC Digital Interface Registers RC_CTL 32-bit Base + 0x0000
Reserved — — (Base + 0x0004) –
(Base + 0x007F)
SIRC Digital Interface 0xC3FE_0080
Slow Power RC Control Register LPRC_CTL 32-bit Base + 0x0000
Reserved — — (Base + 0x0004) –
(Base + 0x009F)
FMPLL 0xC3FE_00A0
Control Register PLLD0_CR 32-bit Base + 0x0000
PLLD Modulation Register PLLD0_MR 32-bit Base + 0x0004
Reserved — — (Base + 0x0008) –
(Base + 0x00FF)
CMU 0xC3FE_0100
Control Status Register CMU_CSR 32-bit Base + 0x0000
Frequency Display Register CMU_FDR 32-bit Base + 0x0004
High Frequency Reference Register CMU_HFREFR_A 32-bit Base + 0x0008
Low Frequency Reference Register CMU_LFREFR_A 32-bit Base + 0x000C
