RX Individual Mask Register 62 RXIMR62 32-bit Base + 0x0978
RX Individual Mask Register 63 RXIMR63 32-bit Base + 0x097C
Reserved — — (Base + 0x0980) –
(Base + 0x3FFF)
FlexCAN_3 0xFFFC_C000
Module Configuration MCR 32-bit Base + 0x0000
Control Register CTRL 32-bit Base + 0x0004
Free Running Timer TIMER 32-bit Base + 0x0008
Reserved — — Base + (0x000C –
0x000F)
Rx Global Mask Register RXGMASK 32-bit Base + 0x0010
Rx 14 Mask Register RX14MASK 32-bit Base + 0x0014
Rx 15 Mask Register RX15MASK 32-bit Base + 0x0018
Error Counter Register ECR 32-bit Base + 0x001C
Error and Status Register ESR 32-bit Base + 0x0020
Interrupt Masks 2 Register IMASK2 32-bit Base + 0x0024
Interrupt Masks 1 Register IMASK1 32-bit Base + 0x0028
Interrupt Flags 2 Register IFLAG2 32-bit Base + 0x002C
Interrupt Flags 1 Register IFLAG1 32-bit Base + 0x0030
Reserved — — Base + (0x0034 –
0x007F)
Message Buffer 0 MB0 128 bits
per MB
Base + 0x0080
Message Buffer 1 MB1 128 bits
per MB
Base + 0x0090
Message Buffer 2 MB2 128 bits
per MB
Base + 0x00A0
Message Buffer 3 MB3 128 bits
per MB
Base + 0x00B0
Message Buffer 4 MB4 128 bits
per MB
Base + 0x00C0
Message Buffer 5 MB5 128 bits
per MB
Base + 0x00D0
Message Buffer 6 MB6 128 bits
per MB
Base + 0x00E0
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
