Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 835
eMIOS_0 UC12 A Register EMIOS0_UC12_A 32-bit Base + 0x01A0
eMIOS_0 UC12 B Register EMIOS0_UC12_B 32-bit Base + 0x01A4
Reserved — — Base + 0x01A8 –
Base + 0x01AB
eMIOS_0 UC12 Control Register EMIOS0_UC12_SC 32-bit Base + 0x01AC
eMIOS_0 UC12 Status Register EMIOS0_UC12_SS 32-bit Base + 0x01B0
Reserved — — Base + 0x01B4 –
Base + 0x01BF
eMIOS_0 UC13 A Register EMIOS0_UC13_A 32-bit Base + 0x01C0
eMIOS_0 UC13 B Register EMIOS0_UC13_B 32-bit Base + 0x01C4
Reserved — — Base + 0x01C8 –
Base + 0x01CB
eMIOS_0 UC13 Control Register EMIOS0_UC13_SC 32-bit Base + 0x01CC
eMIOS_0 UC13 Status Register EMIOS0_UC13_SS 32-bit Base + 0x01D0
Reserved — — Base + 0x01D4 –
Base + 0x01DF
eMIOS_0 UC14 A Register EMIOS0_UC14_A 32-bit Base + 0x01E0
eMIOS_0 UC14 B Register EMIOS0_UC14_B 32-bit Base + 0x01E4
Reserved — — Base + 0x01E8 –
Base + 0x01EB
eMIOS_0 UC14 Control Register EMIOS0_UC14_SC 32-bit Base + 0x01EC
eMIOS_0 UC14 Status Register EMIOS0_UC14_SS 32-bit Base + 0x01F0
Reserved — — Base + 0x01F4 –
Base + 0x01FF
eMIOS_0 UC15 A Register EMIOS0_UC15_A 32-bit Base + 0x0200
eMIOS_0 UC15 B Register EMIOS0_UC15_B 32-bit Base + 0x0204
Reserved — — Base + 0x0208 –
Base + 0x020B
eMIOS_0 UC15 Control Register EMIOS0_UC15_SC 32-bit Base + 0x020C
eMIOS_0 UC15 Status Register EMIOS0_UC15_SS 32-bit Base + 0x0210
Reserved — — Base + 0x0214 –
Base + 0x021F
eMIOS_0 UC16 A Register EMIOS0_UC16_A 32-bit Base + 0x0220
eMIOS_0 UC16 B Register EMIOS0_UC16_B 32-bit Base + 0x0224
eMIOS_0 UC16 CNT EMIOS0_UC16_CNT 32-bit Base + 0x0228
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
