22.3.3 Rx FIFO structure
When the FEN bit is set in the MCR, the memory area from 0x80 to 0xFC (which is normally occupied by
MBs 0 to 7) is used by the reception FIFO engine. Table 22-3 shows the Rx FIFO data structure. The region
0x80–0x8C contains an MB structure which is the port through which the CPU reads data from the FIFO
(the oldest frame received and not read yet). The region 0x90–0xDC is reserved for internal use of the
FIFO engine. The region 0xE0–0xFC contains an 8-entry ID table that specifies filtering criteria for
accepting frames into the FIFO. Table 22-4 shows the three different formats that the elements of the ID
table can assume, depending on the IDAM field of the MCR. Note that all elements of the table must have
the same format. See Section 22.4.8, “Rx FIFO for more information.
0 1010 1010 Transmit a data frame whenever a remote request frame with the
same ID is received. This MB participates simultaneously in both
the matching and arbitration processes. The matching process
compares the ID of the incoming remote request frame with the ID
of the MB. If a match occurs this MB is allowed to participate in the
current arbitration process and the Code field is automatically
updated to ‘1110’ to allow the MB to participate in future arbitration
runs. When the frame is eventually transmitted successfully, the
Code automatically returns to ‘1010’ to restart the process again.
0 1110 1010 This is an intermediate code that is automatically written to the MB
by the MBM as a result of match to a remote request frame. The
data frame will be transmitted unconditionally once and then the
code will automatically return to ‘1010’. The CPU can also write
this code with the same effect.
Table 22-6. Message buffer code for Tx buffers (continued)
RTR
Initial Tx
code
Code after
successful
transmission
Description
