Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
824 Freescale Semiconductor
IFER Interrupt Filter Enable Register IFER 32-bit Base + 0x0030
Reserved — — Base + (0x0034 –
0x003F)
Pad Configuration Register 0 PCR0 16-bit Base + 0x0040
Pad Configuration Register 1 PCR1 16-bit Base + 0x0042
Pad Configuration Register 2 PCR2 16-bit Base + 0x0044
Pad Configuration Register 3 PCR3 16-bit Base + 0x0046
Pad Configuration Register 4 PCR4 16-bit Base + 0x0048
Pad Configuration Register 5 PCR5 16-bit Base + 0x004A
Pad Configuration Register 6 PCR6 16-bit Base + 0x004C
Pad Configuration Register 7 PCR7 16-bit Base + 0x004E
Pad Configuration Register 8 PCR8 16-bit Base + 0x0050
Pad Configuration Register 9 PCR9 16-bit Base + 0x0052
Pad Configuration Register 10 PCR10 16-bit Base + 0x0054
Pad Configuration Register 11 PCR11 16-bit Base + 0x0056
Pad Configuration Register 12 PCR12 16-bit Base + 0x0058
Pad Configuration Register 13 PCR13 16-bit Base + 0x005A
Pad Configuration Register 14 PCR14 16-bit Base + 0x005C
Pad Configuration Register 15 PCR15 16-bit Base + 0x005E
Pad Configuration Register 16 PCR16 16-bit Base + 0x0060
Pad Configuration Register 17 PCR17 16-bit Base + 0x0062
Pad Configuration Register 18 PCR18 16-bit Base + 0x0064
Pad Configuration Register 19 PCR19 16-bit Base + 0x0066
Pad Configuration Register 20 PCR20 16-bit Base + 0x0068
Pad Configuration Register 21 PCR21 16-bit Base + 0x006A
Pad Configuration Register 22 PCR22 16-bit Base + 0x006C
Pad Configuration Register 23 PCR23 16-bit Base + 0x006E
Pad Configuration Register 24 PCR24 16-bit Base + 0x0070
Pad Configuration Register 25 PCR25 16-bit Base + 0x0072
Pad Configuration Register 26 PCR26 16-bit Base + 0x0074
Pad Configuration Register 27 PCR27 16-bit Base + 0x0076
Pad Configuration Register 28 PCR28 16-bit Base + 0x0078
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
