Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 833
eMIOS_0 UC3 A Register EMIOS0_UC3_A 32-bit Base + 0x0080
eMIOS_0 UC3 B Register EMIOS0_UC3_B 32-bit Base + 0x0084
Reserved — — Base + 0x0088 –
Base + 0x008B
eMIOS_0 UC3 Control Register EMIOS0_UC3_SC 32-bit Base + 0x008C
eMIOS_0 UC3 Status Register EMIOS0_UC3_SS 32-bit Base + 0x0090
Reserved — — Base + 0x0094 –
Base + 0x009F
eMIOS_0 UC4 A Register EMIOS0_UC4_A 32-bit Base + 0x00A0
eMIOS_0 UC4 B Register EMIOS0_UC4_B 32-bit Base + 0x00A4
Reserved — — Base + 0x00A8 –
Base + 0x00AB
eMIOS_0 UC4 Control Register EMIOS0_UC4_SC 32-bit Base + 0x00AC
eMIOS_0 UC4 Status Register EMIOS0_UC4_SS 32-bit Base + 0x00B0
Reserved — — Base + 0x00B4 –
Base + 0x00BF
eMIOS_0 UC5 A Register EMIOS0_UC5_A 32-bit Base + 0x00C0
eMIOS_0 UC5 B Register EMIOS0_UC5_B 32-bit Base + 0x00C4
Reserved — — Base + 0x00C8 –
Base + 0x00CB
eMIOS_0 UC5 Control Register EMIOS0_UC5_SC 32-bit Base + 0x00CC
eMIOS_0 UC5 Status Register EMIOS0_UC5_SS 32-bit Base + 0x00D0
Reserved — — Base + 0x00D4 –
Base + 0x00DF
eMIOS_0 UC6 A Register EMIOS0_UC6_A 32-bit Base + 0x00E0
eMIOS_0 UC6 B Register EMIOS0_UC6_B 32-bit Base + 0x00E4
Reserved — — Base + 0x00E8 –
Base + 0x00EB
eMIOS_0 UC6 Control Register EMIOS0_UC6_SC 32-bit Base + 0x00EC
eMIOS_0 UC6 Status Register EMIOS0_UC6_SS 32-bit Base + 0x00F0
Reserved — — Base + 0x00F4 –
Base + 0x00FF
eMIOS_0 UC7 A Register EMIOS0_UC7_A 32-bit Base + 0x0100
eMIOS_0 UC7 B Register EMIOS0_UC7_B 32-bit Base + 0x0104
Reserved — — Base + 0x0108 –
Base + 0x010B
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
