Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
862 Freescale Semiconductor
INTC 0xFFF4_8000
Block Configuration Register INTC_PBCR 32-bit Base + 0x0000
Reserved — — Base + (0x0004 –
0x0007)
Current Priority Register INTC_CPR 32-bit Base + 0x0008
Reserved — — Base + (0x000C –
0x000F)
Interrupt Acknowledge Register INTC_IACKR 32-bit Base + 0x0010
Reserved — — Base + (0x0014 –
0x0017)
End of Interrupt Register INTC_EOIR 32-bit Base + 0x0018
Reserved — — Base + (0x001C –
0x001F)
Software Set/Clear Interrupt Register INTC_SSCIR0_3 32-bit Base + 0x0020
Software Set/Clear Interrupt Register INTC_SSCIR4_7 32-bit Base + 0x0024
Reserved — — Base + (0x0028 –
0x003F)
Priority Select Register INTC_PSR0_3 32-bit Base + 0x0040
Priority Select Register INTC_PSR4_7 32-bit Base + 0x0044
Priority Select Register INTC_PSR8_11 32-bit Base + 0x0048
Priority Select Register INTC_PSR12_15 32-bit Base + 0x004C
Priority Select Register INTC_PSR16_19 32-bit Base + 0x0050
Priority Select Register INTC_PSR20_23 32-bit Base + 0x0054
Priority Select Register INTC_PSR24_27 32-bit Base + 0x0058
Priority Select Register INTC_PSR28_31 32-bit Base + 0x005C
Priority Select Register INTC_PSR32_35 32-bit Base + 0x0060
Priority Select Register INTC_PSR36_39 32-bit Base + 0x0064
Priority Select Register INTC_PSR40_43 32-bit Base + 0x0068
Priority Select Register INTC_PSR44_47 32-bit Base + 0x006C
Priority Select Register INTC_PSR48_51 32-bit Base + 0x0070
Priority Select Register INTC_PSR52_55 32-bit Base + 0x0074
Priority Select Register INTC_PSR56_59 32-bit Base + 0x0078
Priority Select Register INTC_PSR60_63 32-bit Base + 0x007C
Priority Select Register INTC_PSR64_67 32-bit Base + 0x0080
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
