Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 839
eMIOS_1 UC5 B Register eMIOS1_UC5_B 32-bit Base + 0x00C4
Reserved — — Base + 0x00C8 –
Base + 0x00CB
eMIOS_1 UC5 Control Register eMIOS1_UC5_SC 32-bit Base + 0x00CC
eMIOS_1 UC5 Status Register eMIOS1_UC5_SS 32-bit Base + 0x00D0
Reserved — — Base + 0x00D4 –
Base + 0x00DF
eMIOS_1 UC6 A Register eMIOS1_UC6_A 32-bit Base + 0x00E0
eMIOS_1 UC6 B Register eMIOS1_UC6_B 32-bit Base + 0x00E4
Reserved — — Base + 0x00E8 –
Base + 0x00EB
eMIOS_1 UC6 Control Register eMIOS1_UC6_SC 32-bit Base + 0x00EC
eMIOS_1 UC6 Status Register eMIOS1_UC6_SS 32-bit Base + 0x00F0
Reserved — — Base + 0x00F4 –
Base + 0x00FF
eMIOS_1 UC7 A Register eMIOS1_UC7_A 32-bit Base + 0x0100
eMIOS_1 UC7 B Register eMIOS1_UC7_B 32-bit Base + 0x0104
Reserved — — Base + 0x0108 –
Base + 0x010B
eMIOS_1 UC7 Control Register eMIOS1_UC7_SC 32-bit Base + 0x010C
eMIOS_1 UC7 Status Register eMIOS1_UC7_SS 32-bit Base + 0x0110
Reserved — — Base + 0x0114 –
Base + 0x011F
eMIOS_1 UC8 A Register eMIOS1_UC8_A 32-bit Base + 0x0120
eMIOS_1 UC8 B Register eMIOS1_UC8_B 32-bit Base + 0x0124
eMIOS_1 UC8 CNT eMIOS1_UC8_CNT 32-bit Base + 0x0128
eMIOS_1 UC8 Control Register eMIOS1_UC8_SC 32-bit Base + 0x012C
eMIOS_1 UC8 Status Register eMIOS1_UC8_SS 32-bit Base + 0x0130
Reserved — — Base + 0x0134 –
Base + 0x013F
eMIOS_1 UC9 A Register eMIOS1_UC9_A 32-bit Base + 0x0140
eMIOS_1 UC9 B Register eMIOS1_UC9_B 32-bit Base + 0x0144
Reserved — — Base + 0x0148 –
Base + 0x014B
eMIOS_1 UC9 Control Register eMIOS1_UC9_SC 32-bit Base + 0x014C
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
