MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 289
16.6.1 Interrupt request sources
The INTC has two types of interrupt requests, peripheral and software configurable. These interrupt
requests can assert on any clock cycle.
16.6.1.1 Peripheral interrupt requests
An interrupt event in a peripheral’s hardware sets a flag bit that resides in the peripheral. The interrupt
request from the peripheral is driven by that flag bit.
The time from when the peripheral starts to drive its peripheral interrupt request to the INTC to the time
that the INTC starts to drive the interrupt request to the processor is three clocks.
External interrupts are handled by the SIU (see Section 19.6.3, “External interrupts).
16.6.1.2 Software configurable interrupt requests
An interrupt request is triggered by software by writing a 1 to a SETx bit in
INTC_SSCIR0_3–INTC_SSCIR4_7. This write sets the corresponding flag bit, CLRx, resulting in the
interrupt request. The interrupt request is cleared by writing a 1 to the CLRx bit.
The time from the write to the SETx bit to the time that the INTC starts to drive the interrupt request to the
processor is four clocks.
16.6.1.3 Unique vector for each interrupt request source
Each peripheral and software configurable interrupt request is assigned a hardwired unique 9-bit vector.
Software configurable interrupts 0–7 are assigned vectors 0–7 respectively. The peripheral interrupt
requests are assigned vectors 8 to as high as needed to include all the peripheral interrupt requests. The
peripheral interrupt request input ports at the boundary of the INTC block are assigned specific hardwired
vectors within the INTC (see Table 16-1).
16.6.2 Priority management
The asserted interrupt requests are compared to each other based on their PRIx values set in the INTC
Priority Select Registers (INTC_PSR0_3–INTC_PSR208_210). The result is compared to PRI in the
associated INTC_CPR. The results of those comparisons manage the priority of the ISR executed by the
associated processor. The associated LIFO also assists in managing that priority.
214 0x0B58 4 Reserved
215 0x0B5C 4 Reserved
216 0x0B60 4 Reserved
Table 16-10. Interrupt vector table (continued)
IRQ # Offset
Size
(bytes)
Interrupt Module
