MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 279
16.5.2.6 INTC Priority Select Registers (INTC_PSR0_3–INTC_PSR208_210)
Offset: 0x0040 Access: User read/write
0123456789101112131415
R
0000 PRI0 0000 PRI1
W
Reset
0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
0000 PRI2 0000 PRI3
W
Reset
0000000000000000
Figure 16-9. INTC Priority Select Register 0–3 (INTC_PSR[0:3])
Offset: 0x0110 Access: User read/write
0123456789101112131415
R0 0 0 0
PRI208
0000
PRI209
W
Reset
0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R0 0 0 0
PRI210
00000000
W
Reset
0000000000000000
Figure 16-10. INTC Priority Select Register 208-210 (INTC_PSR[208:210])
Table 16-8. INTC_PSR0_3–INTC_PSR208_210 field descriptions
Field Description
PRI Priority Select
PRIx selects the priority for interrupt requests. See Section 16.6, “Functional description.
Table 16-9. INTC Priority Select Register address offsets
INTC_PSRx_x Offset address INTC_PSRx_x Offset address
INTC_PSR0_3 0x0040 INTC_PSR108_111 0x00AC
INTC_PSR4_7 0x0044 INTC_PSR112_115 0x00B0
INTC_PSR8_11 0x0048 INTC_PSR116_119 0x00B4
INTC_PSR12_15 0x004C INTC_PSR120_123 0x00B8
