10.2 External Signal Description
The MC_PCU has no connections to any external pins.
10.3 Memory Map and Register Definition
NOTE
Any access to unused registers as well as write accesses to read-only
registers will:
• not change register content
• cause a transfer error
Table 10-1. MC_PCU Register Description
Address Name Description Size
Access
Location
Supervisor
0xC3FE_8000 PCU_PCONF0 Power Domain #0 Configuration word read on page 215
0xC3FE_8004 PCU_PCONF1 Power Domain #1 Configuration word read on page 216
0xC3FE_8008 PCU_PCONF2 Power Domain #2 Configuration word read/write on page 217
0xC3FE_8040 PCU_PSTAT Power Domain Status Register word read on page 217
Table 10-2. MC_PCU Memory Map
Address Name
01232756789101112131415
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
0xC3FE
_8000
PCU_PCONF0 R0000000000000000
W
R0 0
STBY0
00
STOP
0
HALT
RUN3 RUN2 RUN1 RUN0
DRUN
SAFE
TEST
RST
W
0xC3FE
_8004
PCU_PCONF1 R0000000000000000
W
R0 0
STBY0
00
STOP
0
HALT
RUN3 RUN2 RUN1 RUN0
DRUN
SAFE
TEST
RST
W
0xC3FE
_8008
PCU_PCONF2 R0000000000000000
W
R0 0
STBY0
00
STOP
0
HALT
RUN3 RUN2 RUN1 RUN0
DRUN
SAFE
TEST
RST
W
