MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 623
25.4.7.2 Normal Conversion Mask Registers (NCMR[0..2])
NCMR0 = Enable bits of normal sampling for channel 0 to 15 (precision channels)
NCMR1 = Enable bits of normal sampling for channel 32 to 47 (standard channels)
NCMR2 = Enable bits of normal sampling for channel 64 to 95 (external multiplexed channels)
Address: Base + 0x00A4 Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CH15 CH14 CH13 CH12 CH11 CH10 CH9 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 CH0
W
Reset0000000000000000
Figure 25-27. Normal Conversion Mask Register 0 (NCMR0)
Address: Base + 0x00A8 Access: User read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CH47 CH46 CH45 CH44 CH43 CH42 CH41 CH40 CH39 CH38 CH37 CH36 CH35 CH34 CH33 CH32
W
Reset0000000000000000
Figure 25-28. Normal Conversion Mask Register 1 (NCMR1)
