NOTE
The implicit channel conversion priority in the case in which all channels
are selected is the following: ADC0_P[0:x], ADC0_S[0:y], ADC0_X[0:z].
The channels always start with 0, the lowest index.
Address:
Base + 0x00AC Access: User read/write
0123456789101112131415
R
CH95 CH94 CH93 CH92 CH91 CH90 CH89 CH88 CH87 CH86 CH85 CH84 CH83 CH82 CH81 CH80
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CH79 CH78 CH77 CH76 CH75 CH74 CH73 CH72 CH71 CH70 CH69 CH68 CH67 CH66 CH65 CH64
W
Reset0000000000000000
Figure 25-29. Normal Conversion Mask Register 2 (NCMR2)
Table 25-20. NCMR field descriptions
Field Description
CHn Sampling enable
When set Sampling is enabled for channel n.
