25.4.3.5 Watchdog Threshold Interrupt Status Register (WTISR)
25.4.3.6 Watchdog Threshold Interrupt Mask Register (WTIMR)
Address: Base + 0x0030 Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
0000000
0
WDG
3H
WDG
2H
WDG
1H
WDG
0H
WDG
3L
WDG
2L
WDG
1L
WDG
0L
W
w1c w1c w1c w1c w1c w1c w1c w1c
Reset0000000000000000
Figure 25-18. Watchdog Threshold Interrupt Status Register (WTISR)
Table 25-13. WTISR field descriptions
Field Description
WDGxH This corresponds to the status flag generated on the converted value being higher than the programmed
higher threshold (for [x = 0..3]).
WDGxL This corresponds to the status flag generated on the converted value being lower than the programmed
lower threshold (for [x = 0..3]).
