MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 613
25.4.3.3 Interrupt Mask Register (IMR)
The Interrupt Mask Register (IMR) contains the interrupt enable bits for the ADC.
Address: Base + 0x001C Access: User read/write
0123456789101112131415
R
EOC_CH95 EOC_CH94 EOC_CH93 EOC_CH92 EOC_CH91 EOC_CH90 EOC_CH89 EOC_CH88 EOC_CH87 EOC_CH86 EOC_CH85 EOC_CH84 EOC_CH83 EOC_CH82 EOC_CH81 EOC_CH80
W w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
EOC_CH79 EOC_CH78 EOC_CH77 EOC_CH76 EOC_CH75 EOC_CH74 EOC_CH73 EOC_CH72 EOC_CH71 EOC_CH70 EOC_CH69 EOC_CH68 EOC_CH67 EOC_CH66 EOC_CH65 EOC_CH64
W w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c
Reset0000000000000000
Figure 25-13. Channel Pending Register 2 (CEOCFR2)
Table 25-10. CEOCFR field descriptions
Field Description
EOC_CHn When set, the measure of channel n is completed.
Address: Base + 0x0020 Access: User read/write
0123456789101112131415
R00000000 00000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R00000000 000
MSKE OCTU
MSK
JEOC
MSK
JECH
MSK EOC MSK
ECH
W
Reset0000000000000000
Figure 25-14. Interrupt Mask Register (IMR)
