Address: Base + 0x0014 Access: User read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
EOC_CH15 EOC_CH14 EOC_CH13 EOC_CH12 EOC_CH11 EOC_CH10
EOC_CH9 EOC_CH8 EOC_CH7 EOC_CH6 EOC_CH5 EOC_CH4 EOC_CH3 EOC_CH2 EOC_CH1 EOC_CH0
W w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c
Reset0000000000000000
Figure 25-11. Channel Pending Register 0 (CEOCFR0)
Address: Base + 0x0018 Access: User read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
EOC_CH47 EOC_CH46 EOC_CH43 EOC_CH44 EOC_CH43 EOC_CH42 EOC_CH41 EOC_CH40 EOC_CH39 EOC_CH38 EOC_CH37 EOC_CH36 EOC_CH35 EOC_CH34 EOC_CH33 EOC_CH32
W w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c w1c
Reset0000000000000000
Figure 25-12. Channel Pending Register 1 (CEOCFR1)
