MPC5604B/C Microcontroller Reference Manual, Rev. 8
36 Freescale Semiconductor
0xC3F9_4000 0xC3F9_7FFF 16 WKPU
0xC3F9_8000 0xC3F9_FFFF 32 Reserved
0xC3FA_0000 0xC3FA_3FFF 16 eMIOS_0
0xC3FA_4000 0xC3FA_7FFF 16 eMIOS_1
0xC3FA_8000 0xC3FD_7FFF 192 Reserved
0xC3FD_8000 0xC3FD_BFFF 16 SSCM
0xC3FD_C000 0xC3FD_FFFF 16 MC_ME
0xC3FE_0000 0xC3FE_3FFF 16 MC_CGM
0xC3FE_4000 0xC3FE_7FFF 16 MC_RGM
0xC3FE_8000 0xC3FE_BFFF 16 MC_PCU
0xC3FE_C000 0xC3FE_FFFF 16 RTC/API
0xC3FF_0000 0xC3FF_3FFF 16 PIT
0xC3FF4000 0xFFDF_FFFF 981040 Reserved
0xFFE0_0000 0xFFE0_3FFF 16 ADC_0
0xFFE0_4000 0xFFE2_FFFF 176 Reserved
0xFFE3_0000 0xFFE3_3FFF 16 I2C_0
0xFFE3_4000 0xFFE3_FFFF 48 Reserved
0xFFE4_0000 0xFFE4_3FFF 16 LINFlex_0
0xFFE4_4000 0xFFE4_7FFF 16 LINFlex_1
0xFFE4_8000 0xFFE4_BFFF 16 LINFlex_2
0xFFE4_C000 0xFFE4_FFFF 16 LINFlex_3
0xFFE5_0000 0xFFE6_3FFF 80 Reserved
0xFFE6_4000 0xFFE6_7FFF 16 CTU
0xFFE6_8000 0xFFE6_FFFF 32 Reserved
0xFFE7_0000 0xFFE7_3FFF 16 CAN sampler
0xFFE7_4000 0xFFE7_FFFF 48 Reserved
0xFFE8_0000 0xFFEF_FFFF 512 Mirrored range 0x3F80000–0xC3FFFFFF
0xFFF0_0000 0xFFF0_FFFF 64 Reserved
0xFFF1_0000 0xFFF1_3FFF 16 MPU
0xFFF1_4000 0xFFF3_7FFF 144 Reserved
0xFFF3_8000 0xFFF3_BFFF 16 SWT
0xFFF3_C000 0xFFF3_FFFF 16 STM
0xFFF4_0000 0xFFF4_3FFF 16 ECSM
Table 3-1. MPC5604B memory map (continued)
Start address End address Size (KB) Region name
