NEC Univerge SV9100 - Page 380

Issue 4.0
2-340 Program 21 : Outgoing Call Setup
06
Permit Code
Table
1
~4
(table)
001
~200
(Entry)
Dial
(Up to 12 digits)
Table 1
~4 = No
Setting
Program the Permit Code
Tables. If the system has Toll
Restriction enabled, users can
dial numbers only if permitted
by these tables and the
Common Permit Table (21-06-
04). There are four Permit
Code Tables, with up to 200
entries in each table. The
system permits calls exactly as
you enter the code.
07
Deny Restriction
Table
1
~4
(table)
1
~60
(Entry)
Dial
(Up to 12 digits)
Table 1
~4 = No
Setting
Program the Restrict Code
Tables. If the system has Toll
Restriction enabled, users
cannot dial numbers listed in
these tables. There are four
Restrict Code Tables, with up
to 200 entries in each table.
The system restricts calls
exactly as you enter the code.
08
PBX Access
Code
1
~4
Dial
(Up to two
digits)
Table 1
~4 = No
Setting
Enter the PBX Access Code.
When the system is behind a
PBX, this is the code users
dial to access a PBX trunk.
Toll Restriction begins after
the PBX access code. For
PBX trunks (Program 14-04)
the system only Toll Restricts
calls that contain the access
code. Always program this
option when the system is
behind a PBX, even if you
don’t want to use Toll
Restriction. PBX Access
Codes can have up to two
digits, using 0-9, #,  and
LINE KEY 1 (don’t care).
When using Account Codes,
do not use an asterisk in a
PBX access code. Otherwise,
after the , the trunk stops
sending digits to the central
office. Entries 1~4 correspond
to the 4 PBX Access Codes.
Each code can have up to two
digits.
09 Specific Dial
Outgoing Code
1
~20
Dial
(Up to eight
digits)
No Setting
Input Data (Continued)
Item
No.
Item Table Input Data Default Description
