NEC Univerge SV9100 - OPX CODEC (QSLAC) Filter Data Setup

Issue 4.0
SV9100 Programming Manual 2-743
Description
Use Program 82-15 : OPX CODEC (QSLAC) Filter Data Setup to define the filter data setup
information (when Program 82-07 is set to 4).
Program 82 : Basic Hardware Setup for Extension
82-15 : OPX CODEC (QSLAC) Filter Data Setup
Level:
IN
Input Data
Item Name Input Data Default
01 B1 Filter Setup(1) 0~255 202
02 B1 Filter Setup(2) 0~255 125
03 B1 Filter Setup(3) 0~255 164
04 B1 Filter Setup(4) 0~255 34
05 B1 Filter Setup(5) 0~255 71
06 B1 Filter Setup(6) 0~255 69
07 B1 Filter Setup(7) 0~255 169
08 B1 Filter Setup(8) 0~255 123
09 B1 Filter Setup(9) 0~255 135
10 B1 Filter Setup(10) 0~255 248
11 B1 Filter Setup(11) 0~255 254
12 B1 Filter Setup(12) 0~255 143
13 B1 Filter Setup(13) 0~255 168
14 B1 Filter Setup(14) 0~255 240
15 B2 Filter Setup(1) 0~255 46
16 B2 Filter Setup(2) 0~255 1
17 AISN and Analog Gains 0~255 50
18 Z Filter Coefficients(1) 0~255 170
19 Z Filter Coefficients(2) 0~255 42
20 Z Filter Coefficients(3) 0~255 106
