NEC Univerge SV9100 - DISA Toll Restriction Class

Issue 4.0
SV9100 Programming Manual 2-415
Description
For systems that use Toll Restriction, use Program 25-11 : DISA Toll Restriction Class to assign a Toll
Restriction Class (1~15) to each DISA user (1~15). The system uses the Toll Restriction Class you enter
in Program 21-05 and 21-06. The Toll Restriction Class assigned to a DISA call is based on the DISA
Class of Service and user, which is determined by the password the caller dials.
When programming, make a separate entry for each Night Service mode.
Conditions
 Program 21-05 cannot be used to assign Toll Restriction to DISA trunks.
Feature Cross Reference

Direct Inward System Access (DISA)
Program 25 : VRS/DISA Setup
25-11 : DISA Toll Restriction Class
Level:
IN
Input Data
DISA User Number 1~15
Item
No.
Day/Night
Mode
Toll
Restriction
Class
Default
01 1~8 1~15 2
