NEC Univerge SV9100 - Networking CODEC Information Basic Setup

Issue 4.0
2-760 Program 84 : Hardware Setup for VoIP
Description
Use Program 84-12 : Networking CODEC Information Basic Setup to set voice (RTP packet)
encoding parameters.
Program 84 : Hardware Setup for VoIP
84-12 : Networking CODEC Information Basic Setup
Level:
IN
Item
No.
Item Input Data Default
01
Number of G.711 Audio Frames
1~4
(10ms steps)
3
02
G.711 VAD mode
0 = Disable
1 = Enable
0
03
G.711 Type
0 = A-law
1 = -law
1
04
G.711 Jitter Buffer (min)
0~300ms
30
05
G.711 Jitter Buffer (average)
0~300ms
60
06
G.711 Jitter Buffer (max)
0~300ms
120
07
Number of G.729 Audio Frames
1~6
3
08
G.729 VAD mode
0 = Disable
1 = Enable
0
09
G.729 Jitter Buffer (min)
0~300ms
30
10
G.729 Jitter Buffer (average)
0~300ms
60
11
G.729 Jitter Buffer (max)
0~300ms
120
17
Jitter Buffer Mode
1 = Static
3 = Self Adjusting
3
18
VAD Threshold
0~30 = -19dB~+10dB
0 = Adaptec Threshold
1 = -19dB(-49dBm)
:
20 = 0dB (-30dBm)
:
29 = 9dBm(-21dBm)
30 = 10dBm(-20dBm)
20
