NEC Univerge SV9100 - GCD-CP10 Network Setup

Issue 4.0
2-24 Program 10 : System Configuration Setup
Description
Use Program 10-12 : GCD-CP10 Network Setup to setup the IP Address, Subnet-Mask, and Default
Gateway addresses.
Program 10 : System Configuration Setup
10-12 : GCD-CP10 Network Setup
Level:
SA
Input Data
Item
No.
Item Input Data Default Description
01 IP Address
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
192.168.0.10
Set for
GCD-CP10.
02 Subnet
Mask
128.0.0.0
240.0.0.0
254.0.0.0
255.192.0.0
255.248.0.0
255.255.0.0
255.255.224.0
255.255.252.0
255.255.255.128
255.255.255.240
255.255.255.254
192.0.0.0
248.0.0.0
255.0.0.0
255.224.0.0
255.252.0.0
255.255.128.0
255.255.240.0
255.255.254.0
255.255.255.192
255.255.255.248
255.255.255.255
224.0.0.0
252.0.0.0
255.128.0.0
255.240.0.0
255.254.0.0
255.255.192.0
255.255.248.0
255.255.255.0
255.255.255.224
255.255.255.252
255.255.255.0
The setting of
Subnet Mask is
invalid when all
Host Addresses
are 0.
If the network
section is:
0,
127,
128.0,
191.255,
192.0.0,
223.255.255
The setting of
Subnet Mask is
invalid.
03 Default
Gateway
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0
IP Address for
Router.
