NEC Univerge SV9100 - DTMF Tone Setup

Issue 4.0
2-680 Program 80 : Basic Hardware Setup for System
Description
Use Program 80-02 : DTMF Tone Setup to define the duration (On time) and pause (Off time) for DTMF
dialing. This option affects all trunk line calls system wide. Make separate entries for duration and pause.
It is also possible to adjust the level of both high and low frequency tone.
Program 80 : Basic Hardware Setup for System
80-02 : DTMF Tone Setup
Level:
MF
Input Data
Item
No.
Item Input Data Default
01
Duration
1~255 5 (100ms)
02
Pause
1~255 5 (100ms)
03
Tone Level (Low) (dB)
1~97
-45
:
+3
65 (-13dB)
04
Tone Level (High) (dB)
1~97
-45
:
+3
69 (-11dB)
Duration
Pause
