Issue 4.0
2-552 Program 44 : ARS/F-Route Setup
Description
When Program 44-02-02 is set to type 3, use Program 44-03 : Dial Analysis Extension Table to set
the dial extension analysis table. These tables are used when the analyzed digits must be more than
eight digits. If the received digits do not match the digits set in tables 1~250, table number 252 is used to
refer to the next Extension Table Area (1~4) to be searched. If the received digits are not identified in
tables 1~250, the F-Route selection table number defined in table 251 is used.
Program 44 : ARS/F-Route Setup
44-03 : Dial Analysis Extension Table
Level:
IN
Input Data
Extension Table Area Number 1~4
Dial Analysis Table Number 1~252
Dial Analysis Table Number : 1~250
Item
No.
Item Input Data Default
01
Dial
Up to 24 digits
Digits = 1~9, 0,
, #, @
(Press Line Key 1 for wild character @)
No Setting
02
ARS/F-Route Select
Table Number
0~500 (ARS/F-Route Table Number)
With Program 44-01 set to 0, Program 44-05 is
checked.
With Program 44-01 set to 1, Program 44-04 is
checked.
0
