2-558 Program 44 : ARS/F-Route Setup
Description
Use Program 44-07 : Gain Table for ARS/F-Route Access to set the gain/PAD table. If an extension dials
ARS/F-Route number:
 The Extension Dial Gain Table, assigned in Program 44-05, is activated.
 The Extension Dial Gain Table follows Outgoing transmit and Outgoing receive settings.
If the incoming call is transferred to another line using ARS/F-Route:
 The Tandem Gain Table, assigned in Program 44-05, is activated.
 The Tandem Gain Table follows the Incoming transmit and Incoming receive settings for incoming line,
and Outgoing transmit and Outgoing receive settings for the outgoing line.
Program 44 : ARS/F-Route Setup
44-07 : Gain Table for ARS/F-Route Access
Level:
IN
NOTE

For ARS/F-Route calls, the CODEC gains defined in Program 14-01-02 and 14-01-03
are not activated.
Input Data
Gain Table Number 1~500
Item
No.
Item Input Data Default
01
Incoming Transmit
1~57
(-15.5 ~ +12.5dB)
32
(0dB)
02
Incoming Receive
1~57
(-15.5 ~ +12.5dB)
32
(0dB)
03
Outgoing Transmit
1~57
(-15.5 ~ +12.5dB)
32
(0dB)
04
Outgoing Receive
1~57
(-15.5 ~ +12.5dB)
32
(0dB)
