SV9100 Programming Manual 2-727
Program: 82
Description
Use Program 82-01 : Incoming Ring Tone to set the incoming ring tones, which are the tones a user hears
when a call rings an extension. These tones are grouped into four ring tone Ranges (1~4), also called
patterns, that consist of a combination of frequencies. (You assign a specific Range to trunks in Program
22-03 and to extensions in Program 15-02.) Within each Range there are three frequency Types: High,
Middle and Low. (Service Code 720 allows users to choose the Type for their incoming calls.) Each Type
in turn consists of two frequencies and the modulation played simultaneously to make up the tone.
These frequencies are determined by their Frequency Number selected in Items 1 and 2 (see below). In
this program, you assign the two Frequency Numbers and Modulation for each Type, for each of the four
Ranges. The chart below shows the default Frequency Numbers for each Type in each Range.
Program 82 : Basic Hardware Setup for Extension
82-01 : Incoming Ring Tone
Level:
MF
Input Data
Incoming Ringing Tone Number 1 = Pattern 1 (Trunk Incoming)
2 = Pattern 2 (Trunk Incoming)
3 = Pattern 3 (Trunk Incoming)
4 = Pattern 4 (Trunk Incoming)
5 = Intercom Incoming Pattern
6 = Alarm Sensor Tone Pattern
7 = Pattern 5 (Trunk Incoming)
8 = Pattern 6 (Trunk Incoming)
9 = Pattern 7 (Trunk Incoming)
10 = Pattern 8 (Trunk Incoming)
Ringing Tone Type Number
1 = High
2 = Mid
3 = Low
Item
No.
Item Input Data
01
Frequency 1
1 = 520Hz
2 = 540Hz
3 = 660Hz
4 = 760Hz
5 = 1100Hz
6 = 1400Hz
7 = 2000Hz
02
Frequency 2
To Next Page
