NEC Univerge SV9100 - DT800;DT700 CODEC Information Fixed Mode Setup

Issue 4.0
SV9100 Programming Manual 2-795
Description
Use Program 84-29 : DT800/DT700 CODEC Information Fixed Mode Setup to set the CODEC data of
the DT800/DT700 when it uses Multicast.
Conditions
 When using G.711, PRG 84-29-02 only 10ms, 20ms, 30ms and 40ms are used.
Feature Cross Reference
None
Program 84 : Hardware Setup for VoIP
84-29 : DT800/DT700 CODEC Information Fixed Mode Setup
Level:
IN
Input Data
Type
1 = Type 1 (Multicast)
2 = Type 2 (reserved)
3 = Type 3 (reserved)
4 = Type 4 (reserved)
5 = Type 5 (reserved)
Item
No.
Item Input Data Default
01
Audio Capability
1 = G.711 A-law
2 = G.711 -law
3 = G.729
5 = G.722
2
02
Number of Audio Frames
1~6
1 = 10ms
2 = 20ms
3 = 30ms
4 = 40ms
5 = 50ms
6 = 60ms
2
03
RTP Filter
To avoid incorrect voice pass connection, this
Program checks the sending side address from
received RTP packet at VoIPDB.
0 = Disable
1 = Enable
1
