Issue 4.0
2-442 Program 30 : DSS/DLS Console Setup
Description
Use Program 30-02 : DSS Console Extension Assignment to identify which extensions have DSS
Consoles connected.
Up to 32 different extensions with DSS Consoles can be set up. A single extension can have up to four
60-button DSS Consoles (32 is the maximum allowed per system).
When programming, each extension/DSS Console(s) combination is called a Console Number. There
are 32 Console Numbers (1~32). Console Numbers can be assigned to extensions. When entering data,
the assignment for Console Number 1 is normally made first.
Conditions
None
Feature Cross Reference
Direct Station Selection (DSS) Console
Program 30 : DSS/DLS Console Setup
30-02 : DSS Console Extension Assignment
Level:
IN
Input Data
60-button DSS Console Number 01~32
Item
No.
Item Default
01
Extension Number
Enter the extension number for the multiline terminal connected with the DSS
console (up to eight digits).
No Setting
