2-22 Program 10 : System Configuration Setup
Description
Use Program 10-09 : DTMF and Dial Tone Circuit Setup to allocate the circuits on the GCD-CP10 for
either DTMF receiving or dial tone detection. The GCD-CP10 has 80 circuits initially, and an addition 64
circuits are added when a GPZ-BS10 is installed. These are used as follows:
Extension DTMF receiver for single line telephone
Trunk DTMF receiver for analog trunks, dial tone & busy tone detection for analog trunks
Program 10 : System Configuration Setup
10-09 : DTMF and Dial Tone Circuit Setup
Level:
IN
Input Data
Circuit/Resource Number 01~144
Item
No.
Input Data Default Setting
01
0 = Common Use
1 = Extension Only
2 = Trunk Only
The GCD-CP10 has 80
channel DSP resources
(receivers) only for basic
chassis. When a GPZ-BS10 is
installed there are 64 DSP
resources (receivers) available.
In case 0 = Common is
selected and if 14-02-10 (Caller
ID receive ability) is set to
“Yes”, DSP resources are always
allocated to analog trunks not
analog extensions. If 14-02-10 is
set to “No”, DSP resources can
be used for both analog trunks
and analog extensions.
Circuit/Resource 01~32 = 1 (Extensions)
Circuit/Resource 33~80 = 2 (Trunks)
Circuit/Resource 81~144 = 0
