Issue 4.0
SV9100 Programming Manual 2-483
04
Route Table Setup of Target Dial
Set how the system uses the route data (gathered
in Item 3) to route incoming ANI/DNIS calls.
If option 2 is selected, and the call is to be routed
using the DID table (1), up to 8 digits can be
matched. The number of expected digits set in
Program 22-09-01 must match the ANI digits
defined in Program 22-11-01. For example, if an
ANI/DNIS number received was
20355512343001 and Program 22-09-01=4,
the entry in 22-11-01 must be 1234 with the defined
target extension.
If the call is to be routed using the
SPD table (0), up
to 24 digits can be matched. Define the range of the
SPD table to be used in Program 34-09-06. The
data is compared to the entries in Program 13-04-
01 and then routed according to Program 13-04-03.
0 = SPD Table (Program
13-03)
1 = DID Table (Program 22-
11)
0 13-04-01
13-04-03
22-09-01
22-11
34-09-05
34-09-06
05
ANI/DNIS Display as Target Dial Name
Set whether or not ANI data should appear on
telephone displays as part of Caller ID display.
0 = Display Off
1 = Display On
1 13-04
20-09-02
22-11-03
23-09-04
06
Routing SPD Table Setup
Define which part of the
SPD Table set up in
Program 13-04 the system uses for ANI/DNIS
Caller ID look-ups and ANI/DNIS routing.
This is required if Items 04 and 05 above are 1
(Caller ID on). When you specify a starting and end
address, the system uses the part of the table for
look-ups.
When you specify a starting address and length, the
system uses that part of the table for routing. If the
incoming ANI/DNIS number data matches the
Number entry in the table, the system routes
according to the associated Name data. That data
can be an extension, Department Group pilot
number, the voice mail master number or a trunk
ring group.
Start = 0, 100~9990
End = 0, 99~9999
Start = 1000
End = 1199
13-04
07
Routing on ANI/DNIS Error
Determine how the system handles an ANI/DNIS
call if a data error is detected in the incoming data
string.
0 = Play Busy Tone to
Caller
1 = Route Caller to Ring
Group Specified in
Program 25-03
(Transfer)
1 25-03
Item
No.
Name Input Data
Default
Related
Program
COS 2~15
